项目Items
|
技术指标
Value
|
检测仪器
Test Instrument
|
检测标准
Test Method
|
|
颜色 Color
|
粉红色
Pink
|
目视Visual
|
--
|
|
厚度(mm)
Thickness
|
0.2~14
|
PEACOCK厚度规
PEACOCK THICKNESS METER
|
ASTM D374
|
|
规格
Specification
|
根据客户要求
Can be Custom-made
|
--
|
ASTM D1204
|
|
密度(g/cc)
Density
|
2.62(±0.5)
|
BS-H电子天平
BS-H ELECTRONIC BALANCE
|
ASTM D792
|
|
硬度(Shore C)
Hardness
|
10~55(±5)
|
LX-C型微孔材料硬度计
LX-C CELLULAR MATERIAL DUROMETER
|
ASTM D2240
|
|
导热系数(W/m.K)
Thermal Conductivity
|
1.5(±0.2)
|
Long-Win9389导热系数测试仪
Long-Win9389 THERMAL CONDUCTIVITY TESTER
|
ASTM D5470
|
|
热阻(℃in2/W)(@20psi&1mm)
Thermal Resistance
|
≤1.5
|
DRL-Ⅲ导热系数测试仪
DRL-Ⅲ THERMAL CONDUCTIVITY TESTER
|
ASTM D5470
|
|
击穿电压(KV)(@1mm)
Breakdown Voltage
|
≥8
|
MS2676A耐压测试仪
MS2676A WITHSTAND VOLTAGE TESTER
|
ASTM D149
|
|
体积电阻率(Ω.cm)
Volume Resistivity
|
≥108
|
ZC-36高绝缘电阻测量仪
ZC-36 HIGH DIELECTRIC RESISTANCE TESTER
|
ASTM D257
|
|
压缩比(%)(@50psi)
Compression Ratio
|
≥35
|
压缩力测试仪
COMPRESSINVE FORCE TESTER
|
ASTM D575-1991
|
|
拉伸强度 (Mpa)
Tensile Strength
|
≥0.3
|
拉力试验机
TENSION TESTER
|
ASTM D412-1998A
|
|
延伸率(%) Elongation
|
≥80
|
|
介电常数(@1MHz)
Dielectric Constant
|
≥5
|
WY2851D数显Q表
WY2851D DIGITAL Q METER
|
ASTM D150
|
|
介质损耗 Dielectric Loss
|
≤0.1
|
|
防火性能 UL Certify
|
UL94V0,5V
|
阻燃测试仪 FLAME RATING TESTER
|
UL 94
|
|
热失重%（120℃,7d）
Thermal Gravimetry
|
≤2
|
可程式恒温横湿试验箱 PROGRAMMABLE CONTANT TEMPERATURE AND HUMIDITY TESTING MACHINE
|
ASTM E595-2006
|
|
使用温度 (℃)
Operating Temperature
|
-50~180
|
可程式冷热冲击箱
PROGRAMMABLE THERMAL SHOCK TESTER
|
--
|
